200MHz带宽,1GHz采样,2通道USB接口虚拟示波器

200 MHz 带宽,2 通道, 64M/每通道 存储深度
1GSa/s 采样 高速 USB 2.0/3.0,接口,二次开发,Labview驱动。
生产厂商: 安捷伦公司 产品型号: U2702A
产品简介: 200 MHz 带宽,2 通道, 64M/每通道 存储深度 1GSa/s 采样 高速 USB 2.0/3.0,接口,二次开发,Labview驱动。

主要特性与技术指标

100 MHz 带宽

  • 2 通道
  • 32M/每通道 存储深度
  • 1GSa/s 采样
  • 高速 USB 2.0,接口 USBTMC-USB488 标准 ( 支持Windows 操作系统。)

Features

  • Waveform Zoom and Maths Function
  • 26 pre-build automatic measurement
  • FFT including max peak search
  • Advance Triggering including edge, pulse width and line selectable video

描述

The U2702A is a 2-channel 8-bit 200MHz Oscilloscope. It uses the common non-proprietary standard high-speed USB 2.0 interface that provides ease of connectivity – allowing users to set up and configure their test swiftly with its plug and play feature.

Through individual windows on your PC screen, the bundled Agilent Measurement Manager (AMM) software provides a familiar front-panel interface for each of the modular instruments. AMM helps you perform quick configuration and measurement acquisition as well as flexible analysis of measured data.

Scope SFP

The U2701A can function as a standalone module. It can also be used as a modular device, providing expansion capabilities and compact solution when used with the other modules in USB Modular Instruments and DAQ family.

With the included IVI-COM drivers, these scopes are compatible with popular development environments including Agilent VEE, Microsoft® Visual Studio® .NET, C/C++ and Visual Basic 6, the Microsoft .NET Framework and LabVIEW. Their small size makes these scopes ideal for standalone bench use as well as integration into system solutions with the U2781A chassis. Hi-Speed USB 2.0 compatibility makes connection to a PC quick and easy.

Capturing and reviewing of configuration commands can be easily logged using the Command Logger bundled in the AMM software. The Code Converter helps ease programming for users by converting the Command logger files to snippets of VEE, VB, C++, and C# codes.

Agilent U2700A series USB Modular Instruments has won Design News’ Golden Mousetrap Award in the 2009 Best Products Category. The Design News’ Awards Program has recognized engineering innovation and creativity in product design for more than two decades.
